JWT Authentication and Role-Based Authorization with .NET 9 and Scalar in Visual Studio 2022

Securing APIs is a critical aspect of modern web development. Implementing JWT (JSON Web Token) authentication combined with role-based authorization ensures that only authenticated users with appropriate permissions can access specific resources. This guide provides a step-by-step approach to setting up JWT authentication and role-based authorization in a .NET 9 Web API using Visual Studio 2022, with Scalar for API documentation.

1. Create a new ASP.NET Core Web API project:

   • Open Visual Studio 2022.

   • Click on "Create a new project."

   • Select "ASP.NET Core Web API" and click "Next."

   • Name your project (e.g., JwtAuthDemo) and choose a location. Click "Next."

   • In the "Additional Information" dialog:

     • Target Framework: .NET 9.0

     • Authentication Type: "None"

     • Check "Use controllers (uncheck to use minimal APIs)"

     • Click "Create."

2. Install necessary NuGet packages:

   • Right-click on the project in Solution Explorer and select "Manage NuGet Packages."

   • Install the following packages:

     • Microsoft.AspNetCore.Authentication.JwtBearer

     • Microsoft.AspNetCore.Identity.EntityFrameworkCore

     • Microsoft.EntityFrameworkCore.SqlServer

     • Scalar.AspNetCore

     • Microsoft.AspNetCore.OpenApi

Scalar is a modern alternative to Swagger for API documentation.

1. Configure Scalar in Program.cs.

   builder.Services.AddOpenApi(options =>
   {
       options.AddDocumentTransformer<BearerSecuritySchemeTransformer>();
   });

   var app = builder.Build();

   app.MapOpenApi();
   app.MapScalarApiReference(options =>
   {
       options.WithTheme(ScalarTheme.Moon)
              .WithDarkMode(true)
              .WithDefaultHttpClient(ScalarTarget.CSharp, ScalarClient.HttpClient)
              .WithDarkModeToggle(false)
              .WithPreferredScheme("Bearer")
              .WithHttpBearerAuthentication(bearer =>
              {
                  bearer.Token = "your-bearer-token";
              });
       options.Authentication = new ScalarAuthenticationOptions
       {
           PreferredSecurityScheme = "Bearer"
       };
   });


2. Implement BearerSecuritySchemeTransformer:

   public class BearerSecuritySchemeTransformer : IDocumentTransformer
   {
       public void Apply(OpenApiDocument document, DocumentTransformerContext context)
       {
           var securityScheme = new OpenApiSecurityScheme
           {
               Type = SecuritySchemeType.Http,
               Scheme = "bearer",
               BearerFormat = "JWT",
               In = ParameterLocation.Header,
               Name = "Authorization",
               Description = "JWT Authorization header using the Bearer scheme."
           };

           document.Components.SecuritySchemes.Add("Bearer", securityScheme);

           document.SecurityRequirements.Add(new OpenApiSecurityRequirement
           {
               {
                   new OpenApiSecurityScheme
                   {
                       Reference = new OpenApiReference
                       {
                           Type = ReferenceType.SecurityScheme,
                           Id = "Bearer"
                       }
                   },
                   new string[] {}
               }
           });
       }
   }
